HDF-13 / Thailand
- Maximum pump flow: 666 L/Min
- Maximum spray pressure: 8 Kg/cm2
- Pump flow (L/min @ head):
+ 150 L/min @ 72m
+ 500 L/min @ 36m
- Dimensions (LxWxH): 130x88x65 cm
- Float material: Composite
- Weight: 71 kg
- Suction method: self-suction
- Pump head: pressure-resistant cast aluminum shell, centrifugal impeller
- Suction diameter: 80mm
- Nozzle diameter: (1x65 + 2x55) mm
- Gasoline engine: Seikoo, Model 188F, 4-stroke, 1 cylinder, air-cooled.
- Engine capacity: 13HP@3600 rpm
- Cylinder capacity: 389cc
- Fuel consumption: 2.3 L/hour
- Fuel tank capacity: 7 L
- Oil capacity: 1.4 L
- Starting method: Self-winding pulley or electric start.
- Ignition method: by IC

HDF-15 / Thailand
- Maximum pump flow: 1200 L/Minute (72m3/hour)
- Maximum spray pressure: 6.5 Kg/cm2
- Pump flow (L/min@head):
+ 350 L/min@60m
+ 850 L/min@40m
- Dimensions (LxWxH): 130x88x65 cm
- Float material: Composite
- Weight: 71kg
- Suction method: self-suction
- Pump head: pressure-resistant cast aluminum shell, centrifugal impeller
- Suction diameter: 80mm
- Nozzle diameter: 80mm or (1x65 + 2x55) mm
- Gasoline engine: Seikoo, Model SK15D, 4-stroke, 1 cylinder, air-cooled.
- Engine capacity: 15HP@3600 rpm
- Cylinder capacity: 420cc
- Fuel consumption: 1.2 liters/hour
- Fuel tank capacity: 7 liters
- Oil capacity: 1.4 liters
- Starting method: Self-winding pulley or electric start.
- Ignition method: by IC

HDF-9 / Thailand
- Maximum pump flow: 450 liters/minute
- Maximum spray pressure: 6.6 kg/cm²
- Pump flow:
+ 175 liters/minute @ 56 m
+ 375 liters/minute @ 27 m
- Maximum suction depth: 3 meters
- Packing size (L x W x H): 56 x 52 x 56 cm (excluding handle)
- Dry weight: 40 kg
- Suction method: Self-suction
- Pump oil: Pressure-resistant cast aluminum housing, zinc impeller
- Suction diameter: 40 mm
- Nozzle diameter: 40 mm
- Gasoline engine: SEIKOO, Model 177F, 4-stroke, 1-cylinder, air-cooled
- Engine capacity: 9 HP @ 3600 rpm
- Cylinder capacity: 270 cc
- Fuel consumption Fuel: 1.6 liters/hour
- Fuel tank capacity: 6.0 liters
- Starting method: Recoil or electric start
- Ignition method: IC board
* Equipment is warranted for 12 months
* Price includes inspection fee
